Key Features & Patented Technologies

1. World’s First Patented One-Click Hard Drive Quick-Release System

CNMZTIND’s exclusive fast-swap HDD/SSD design allows secure installation or removal in seconds—ideal for fleet maintenance, rapid data retrieval, and large-scale deployments.

2. H.265 Video Compression – 50% Better Storage Efficiency

Powered by Hi3521DV100 chipset, H.265 encoding provides the same image quality as H.264, while reducing storage requirements by up to 50%, greatly extending recording time.

3. Real-Time Multi-Channel 1080P Recording

• Supports 4CH or 8CH Full HD 1080P

• PAL: 25fps per channel

• NTSC: 30fps per channel

Perfect for all-round vehicle monitoring, including blind spots, cabin view, rear/side views, and cargo areas.

4. Strong Industrial Design for Harsh Environments

• Fanless, dust-proof, silent cooling

• Aluminum heat-dissipating chassis

• Internal heater for extremely low temperatures

• Dual-level anti-vibration & shock protection (patented)

• Optional anti-theft cage, anti-tamper frame, or 5-in-1 protection box
  (anti-violence / anti-water / anti-tamper / anti-vibration / anti-theft)

5. Smart Power Protection

• Intelligent power management ensures stable vehicle startup

• Illegal power-off protection prevents video corruption

• Short-circuit protection with automatic recovery
  Protects data integrity even during sudden vehicle shutdowns.

6. Full Remote Monitoring via 4G / WiFi / LAN

Supports real-time live view, playback, GPS tracking, and two-way communication through:

• 3G/4G (LTE)

• WiFi

• RJ45 LAN

Ideal for fleet dispatching and remote driver assistance.

7. Flexible Playback Options

Supports 1/4/8-channel synchronous fast playback at
2× / 4× / 8× / 16× / 32× speed.

8. Fully Customizable Accessories

Compatible with CNMZTIND’s full ecosystem:
Cameras (AHD/1080P/180°/IR), monitors, panic button, speaker mic, GPS, trailer cables, and more.

Detailed Technical Specifications

System

• Operating System: Embedded Linux

• Languages: English / Chinese / Russian / Traditional Chinese

• Interface: GUI-based OSD menu

• User Roles: Admin / User passwords

Video

• Inputs: 1–8 channels AHD/analog

• Outputs: VGA + aviation connector outputs

• Preview: Single or 8-channel simultaneous

• Recording Frame Rate:

  • PAL: 25fps per channel

  • NTSC: 30fps per channel

Audio

• 1–8 channel inputs

• 1 channel output

• Audio/video synchronized recording

• ADPCM compression, 8KB/s

Compression & Encoding

• Video Compression: H.265 (VBR/CBR)

• Resolution: CIF / D1 / 720P / 1080P (default: 1080P)

• Bitrate Range: 128kbps – 5Mbps (10-level adjustable)

Storage

• Supports:

  • 2.5″ SATA HDD/SSD (up to 2TB)

  • SD card (up to 256GB)

• Patented quick-release HDD tray

• Dual-storage support

Alarms & Communication

• Alarm Inputs: 4 digital inputs

• Communication: RS232 (expandable), RJ45

• Upgrade: SD card upgrade

Power Supply

• Input: 9V – 36V wide voltage

• Output:

  • 12V ±0.2V (2A max)

  • 5V ±0.2V (2A max)

Why H.265 MDVR is the Best Choice for Modern Fleets

✔ 50% Less Storage = 50% More Recording Time

Perfect for long-haul trucks and buses.

✔ Higher Image Quality at Lower Bitrate

Clearer license plates, facial details, and night images.

✔ Reduced Data Costs for 4G Remote Monitoring

H.265 cuts bandwidth usage almost in half.

✔ Ideal for Large Fleets Across Multiple Regions

More efficient, more stable, and easier to scale.

Ideal Applications

• Logistics & delivery fleets

• Long-haul trucks & trailers

• Public transportation (bus, coach)

• School buses

• Law enforcement & emergency vehicles

• Cold-chain and refrigerated transport

• Waste management & sanitation trucks

• Mining, construction, and heavy machinery

• Taxi & ride-share vehicles
